XYExAP Explosion-proof Wireless Base Station

The XYExAP Explosion-Proof Wireless Base Station is a product developed for wireless local area network applications in explosive and hazardous environments. It is especially suitable for use in petroleum, chemical, pharmaceutical, and hazardous chemical storage industries, as well as civilian applications. This includes production, logistics, and storage processes at hazardous goods manufacturing sites—such as those handling explosives—as well as environments like oil and gas drilling platforms.

Product Inquiry

Category:

Product

Keyword： XYExAP Explosion-proof Wireless Base Station

Advantage

Supports Fat (Fat) and Fit (Slim) working modes, and can be flexibly switched through the interface according tonetworking requirements

Can workin 2.46&5.8GHz frequency band, providing a 1300Mbps wireless rate, dual-band concurrent,and priority connection to 5G

Strong anti-interference, can flexibly adjust AP transmit power, improve wireless stability

Built-in hardware watchdog, automatic recoveryof equipment abnormalities, to ensure the reliability ofthe system

Support user restriction based on SSlD and flexibly allocate network resources

Support seamless roaming, can achieve zero handover, no packet loss, and users can't feel the handover work between APs when they are moving

Support WEP/WPA/WPA2 authentication function

Support access to AC controller for wireless user management and traffic monitoring

Support POE power supply, convenient for flexible eauipment lavout and simple construction

Industrial-grade design, support power supply and interface isolation protection

Explosion-proof: Zone1, Zone 21

Parameter

Model	XYExAP
Standards and agreements	10Base-T, comply with IEEE802.3
	100Base-TX complies with IEEE802.3U
	1000Base-T, comply with IEEE 802.3ab
	Wireless LAN, comply with IEEE802.11 b/g/n/a/ac
	Wireless security, comply with IEEE802.11i
	Fast roaming, comply with IEEE802.11r
	PoE, comply with IEEE802.3af/at
Safety regulations	GB4943. UL/CSA 60950. EN/IEC 60950-1. EN/IEC 60950-22
EMC	GB9254-2008. EN301 489、EN55022、FCC Part 15. R5S-210
RF certification	FCCPart 15. EN300328、EN301 893
Operating mode	fat/slim AP mode; >250000H
Total power	<24W
External antenna	4 chanel 8dB detachable antennas
Working frequency	2.4GHz: 2.412GHz ~ 2.472GHz
Working frequency	5.8GHz: 5.18-5.825GHz
Wireless rate	2.4GHz: 450Mbps
Wireless rate	5.8GHz: 867Mbps
Maximum transmit power	500mW (27dBm)
Coverage	80 meters (outdoor open space), 40 meters (indoor coverage distance is related to site environment and obstructions)
Ethernet port	2*10/100/1000M
WLAN function	Recommended number of users to access the 2.4GHz frequency band of the whole machine: 64
WLAN function	Recommended number of access users in the 5-8GHz frequency band of the whole machine: 136
Encryption	WPA (TKIP)、WPA-PSK、WPA2、(AES)
Power supply	POE power supply: 802.3af/802.3at standard (up to 100 meters)
Power supply	Local power supply: 110~220VAC
Fat/Fit mode switch	The default fat AP mode, supports four modes of routing, AP, bridge, and relay
Fat/Fit mode switch	In the thin AP mode, both network ports are LAN, so there is no need to distinguish the network cable sockets
Operating temperature	-40°C ~ 55°C
Storage temperature	-40°C ~ 70℃
Environment humidity	10% ~ 95%RH no condensation
Electrical Interface	2*M20x1.5 explosion-proof sealing joint
Protection level	IP66
Explosion-proof mark	Ex db IIB+H2 T6 Gb, Ex tb IIIC T80°C Db
