XY-FWS Filling Machine

With PLC and touch panel as control system, the batching filling machine integrates non-contact pumps, weighing scales/flow-meters, barcode scanners and printers, as a precision batching filling equipment for petroleum, chemical, food and other industries, especially suitable for filling flavors and e-cigarette oils and similar substances with high precision, frequent change and high purity requirements.

Product Inquiry

Category:

Equipment

Keyword： XY-FWS Filling Machine

Advantage

Off-line and on-line operation optional.
Semi-automatic and automatic filling optional.
Password, IC, ID, QR code optional for identification.
Real-time display filling quantity (orders, number of barrels), mass/volume, flow rate and time.
Precise filling quantity without configure valves.
Change filling products, no need to clean pump.
Can work with MES: selecting filling orders, scanning for error prevention, precise controlling, recording process, alarming and printing labels.

Parameter

Display type	D Off-line: 10-inch HMI / M On-line: 15.6-inch PC
Operation mode	Touch panel
Pump type	Non-contact pump
Pump control mode	Multi-stage speed regulation
Speed range	0-2400rpm
Filling medium	Liquid (viscosity 1-500cP)
Filling speed	Max. 15L/Min
Measuring method	Weighing scale, flow meter
Measuring accuracy	6Kg-calibration value: 1g; display accuracy: 0.2g; Min. weighing: 20g
	15Kg-calibration value: 2g; display accuracy: 0.5g; Min. weighing: 40g
	30Kg-calibration value: 5g; display accuracy: 1g; Min. weighing: 100g
	60Kg-calibration value: 10g; display accuracy: 2g; Min. weighing: 200g
	120Kg-calibration value: 20g; display accuracy: 5g; Min. weighing: 400g
	150Kg-calibration value: 50g; display accuracy: 5g; Min. weighing: 1Kg
System interface	D Off-line version: USB storage, optional filling management software
System interface	M On-line version: WEBAPI/can be connected to MES
Communication interface	RJ45: MODBUS TCP/IP
Error prevention	QR code scanning
Label printing	Label printer
Power supply	AC220V / AC110V
