XY600 Explosion-proof Batch Controller

XY600 is an explosion-proof panel with 32-bit 800MHz RISC CPU and a LlNUX kernel.lt supports most PLCs in industrial control systems.Excellent processing speed and rich software functions can meet requirements of users and widely be used in petroleum,chemical,pharmaceutical and other industries in hazardous environments.

Product Inquiry

Category:

XY600 Loading/filling Controller

Product

Keyword： XY600 Explosion-proof Batch Controller

Advantage

Full metal explosion-proof housing, certification passed for whole device
Explosion-proof designed touch screen, ESD protected, can be operated directly in explosive area Corrosion resistant touch panel to meet harsh environmental requirements
Internal wiring without any electrical exposure
Can be equipped with external explosion-proof USB sleeve, external USB data access
Explosion-proof light, Explosion-proof power switch, Reset button, Emergency stop button, USB interface
Industrial-grade design standard, highly reliability and stability.
Operating environment temperature: -40°C~+60°C
Explosion-proof design, suitable for use in explosive gas environment Zone 1,2, and explosive dust environment Zone 21, 22
Suitable for use in hydrogen environment

Parameter

Model	XY800_7 XY800_7D XY900_7 XY900_7DR XY600_7	XY800_10 XY800_10D XY900_10 XY900_10DR XY600_10	XY800_12 XY800_12D XY900_12 XY900_12DR XY600_12	XY800_15 XY800_10D XY900_10 XY900_10DR
Type	HMI (Human-Machine Interface)
Screen type	TFT_LCD/LED Back light
Screen size	7"	10.4"	12.r	15"
Resolution	800*480	800*600		1024*768
Screen color	16.77Mcolor
Brightness	300 cd/m²		450 cd/m²	420cd/m²
Backlight	50000 hours
Operation	touch panel/key panel(XY600)
CPU	ARM RISC 32Bit 800MHz
Memory	128M NAND Flash , 128M DDR3 DRAM
Expansion storage	1 USB Host(≤16G)
Communication Interface	1* 10M/100Mt ethernet RJ45 port		1*10M/100M ethernet RJ45 port
	1*RS232/RS485/RS422		2*RS232/RS485/RS422
USB	1* USB Host: upload/download programs and store data
	1* USB Slave: upload/download program and set HMI system parameters
Configuration software	XYFD2000
Program download	supports local download via U-disk/download from USB port/network port
Operating temperature	NT： 0-50℃ / LT： -20~60℃ / WT: -40 ~ 60℃(XY900/XY600: -40~55°C)
Sstorage temperature	-10~60°C/-40~70°C
Environment humidity	10 ~ 90 % RH (no condensation)
Voltage level	24VDC, workable range 21 ~ 28V DC
Rated power	4W Max 8W	8W Max 10W	10W Max 12W	13W Max 15W
Electrical Interface	3* M20 explosion-proof sealing joint		4* M20 explosion-proof sealing joint
Button/lndicator	Max 3 (onlyXY800_D)		Max 4 (only XY800_D)
Protection level	IP66/IP65(XY600)
Expbsion-proof mark	XY800: Ex db ib llB+H2 T6 Gb; Ex ib tb IIIC T80°C Db XY800_D: Ex db ib llB T6 Gb; Ex ib tb IIIC T80°C Db XY900: Ex ib nR IIC T6 Gc; Ex ib tb IIIC T80°C Db XY900_DR: Ex nR IIC T6Gc; Ex tb IIIC T80°C Db XY600: Ex db ib llB+H2 T6 Gb; Ex ib tb IIIC T85°C Db
